Wireless base station

Kaida Optoelectronics can provide interconnection solutions such as outdoor fiber, outdoor power, low frequency signal, RF, inter-board power, inter-board high speed, I/O power for wireless base stations.

Date：2024-08-29 16:44

Kaida Optoelectronics can provide interconnection solutions such as outdoor fiber, outdoor power, low frequency signal, RF, inter-board power, inter-board high speed, I/O power for wireless base stations. Products are widely used in outdoor antenna, RRU/AAU, BBU, small cell and other equipment photoelectric connection.

·Outdoor fiber: with thread, bayonet, push-pull, side pull buckle and other locking methods; plug type DLC, MPO, can be installed on site or factory assembly;IP67, working temperature-40--85 ℃, support module floating.
·Outdoor power supply: with thread, bayonet, push-pull, side pull buckle and other locking methods; socket termination methods are: welding, straight plug, gold finger;IP67, lightning protection, field wire and strip-free, rated current 20- 80A.
·Low frequency signal: with thread, bayonet, push-pull and other locking methods; socket termination forms are welding and direct plug, gold finger series;IP67, gigabit and 10 Gigabit transmission.
RF: with thread, push-pull and other locking methods; socket termination methods are: welding, straight plug, gold finger series; excellent PIM, floating connection.
·Inter-board power supply: floating, blind plug, current 20-150A, signal and power can be mixed.
·High-speed between boards: with independent intellectual property rights, with 25G, 40G, 56G and other series of high-speed connector spectrum; modular design, support differential module expansion, support power and high-speed mixed arrangement.
· I/O power supply: meet the board-to-wire use scenario, there are pull ring unlocking and screw fixing forms, and can be wired on site.
